Description
WHAT IS LAMELLA CLARIFIER
The liquid flows upward through the unit, causing it to settle on the inclined parallel plate. The solid settles on the plate and slides into the funnel at the bottom of the device.
Thin-plate flat clarifiers are available in various independent sizes, as well as plate packaging components that can be installed in new or existing concrete tanks.
The stand-alone unit also has a variety of configurations, allowing flocculation before the unit and condensing the sludge into one body in the sludge removal section.
HOW DOES lamella clarifier WORKS
When using, you can choose to add coagulant. The method is to install inclined plate component with an inclination angle of 60 degrees above the suspended layer of sludge. Suspended solids in the raw water, solids or floc alum flowers formed by adding a coagulant are added to the surface area of the inclined plate Accumulate into a thin mud layer, rely on gravity to slide back to the suspended sludge layer, and then sink into the mud hopper. The sewage pipe is discharged into the sludge tank for further treatment or comprehensive utilization. The supernatant gradually rises to the drain of the water collection , which can be directly discharged or reused.
RANGE OF APPLIOCATION
- Primary clarification of wastewater streams
- Backwash water recovery
- Industrial water treatment systems
- Potable water treatment systems
- River water abstraction clarification
- Wash water recovery and recirculation systems
- Wet scrubber and slaking effluent treatment
AVAILABLE DESIGNS
- Flash mix/flocculation tanks with mixers
- Full stainless steel construction
- Concrete tank designs for large flows
- Special coatings and plate materials available
- Integral mechanical sludge thickener
- Access platform and ladder
- Gasketed and removable covers
- Automatic desludging
- Instrumentation and controls
- Chemical feed equipment
- Sludge handling and dewatering
LAMELLA CLARIFIER EQUIPMENT SPECIFICATIONS
Unit is Completely Assembled
Low Installation
Conservative Design 0.2 GPM/Ft2
Completely Automatic, Gravity in Gravity Out
Reduced Floor Space
Large Compartment Flocculation Tanks with Mixer for Extra Retention Time (approximately 50-60 minutes)
