Daf For 15 M3 Electrocoagulator System Dissolved Air Flotation Effective Fine-Solid Separation Unit

Description

What Is DAF Dissolved air flotation

DAF Dissolved air flotation consists of flotation tank, dissolved air system, reflux pipe, dissolved air released system, skimmer (Based on customer needs, there are combined type, traveling type and chain-plate type to choose.), electric cabinet and so on.

Air flotation separation technology of DAGYEE DAF Dissolved air flotation dissolved air into water at certain working pressure. In the process, pressurized water is saturated with dissolved air and is discharged into a flotation vessel. The microscopic air bubbles produced by released air attach to suspended solids and float them to the surface, forming a sludge blanket. A scoop removes the thickened sludge. Finally, it complete purifies the water.

Air flotation technology of DAF dissolved air flotation plays an important role in solid-liquid separation Simultaneously reduce COD, BOD, chroma. Firstly, mix flocculating into raw water and stir thoroughly. After the effective retention time, the raw water enters into the reaction zone where microscopic air bubbles adhere to the floc and then flows into the separation zone. Under the buoyancy effects, the tiny bubbles float the flocs to the surface, forming a sludge blanket. skimmer removes the sludge into the sludge hopper. Then the lower clarified water flows into the clean-water reservoir through the collecting pipe. Some of water are recycled to the flotation tank for the air dissolving system, while others will be discharged.

Why Choose DAF Dissolved Air Flotation

• Total suspended solids (TSS) reduced by up to 97%.
• Chemical oxygen demand (COD) removal rate of up to 60-80%.
• Integrated sludge hopper for easy removal of solid deposits .
• The DAF area provides a static space for the formation of the float.
• Heavy-duty, fully protected, counter-current surface separator that removes surface float.

DAF Dissolved Air Flotation Process

DAGYEE DAF Dissolved Air Flotation Advantage

• The most effective white water / recycling design. Large effective settling area.
• With optional chemical processing stage improved separation efficiency.
• Compact clarifier and reaction cell design surface loading up to 15m3/m2hr.
• Rugged design for easy understanding, operation and maintenance.
• Carbon steel and stainless steel body material design, the lowest cost of ownership.

DAF Dissolved Air Flotation Application

DAF Model	Qm3/h	Piping Connections				Physical Dimensions(m)	Weight	Operating Weight
		Inlet	Outlet	Sludge	Vent	L/L1    W/W1    H/H1	(Kg)	(Kg)
DAF-003	3	DN50	DN50	DN100	DN100	3.7/2.8    2.4/1.16     2.2/1.7	1500	5000
DAF-005	5	DN80	DN80	DN100	DN80	4/3       2.4/1.16        2.2/1.7	1600	7000
DAF-010	10	DN100	DN100	DN100	DN100	4.65/3.8   2.7/1.36     2.4/1.9	2000	12000
DAF-015	15	DN125	DN100	DN150	DN100	5.6/4.5    2.9/1.66      2.5/2	2200	18000
DAF-020	20	DN150	DN150	DN150	DN100	5.9/4.8    3.2/1.96      2.5/2	3000	22000
DAF-030	30	DN150	DN150	DN150	DN100	6.8/5.5    3.2/2.16     2.7/2.2	3800	32000
DAF-040	40	DN200	DN150	DN150	DN100	8/6.7      3.6/2.6      2.7/2.2	5000	45000
DAF-050	50	DN200	DN150	DN150	DN100	8.4/7        3.6/2.6      2.7/2.2	Inquiry Us Quantity： Company Name： Add： Tel： Fax： Your Name * Your Email * Product Name Your Message * Related Products Automatic Lamella Clarifier UPVC Dewatering Tank Rotary Drum Screen Mixer Chamber Continuous Flow SUS304 316 Polymer Preparation Unit K3 K1 Bio Filter Media Mbbr Moving Bed Biological Reactor Wastewater Treatment Plant sus316 Rotary Strainer Screen Wastewater Treatment Sludge Dehydrator Mechanical Dewatering Wastewater Solid Liquid Separator
