  • Oil Water Separation Coagulant Tank Clarifying Circular Daf System Dissolved Air Flotation
  • Oil Water Separation Coagulant Tank Clarifying Circular Daf System Dissolved Air Flotation
  • Oil Water Separation Coagulant Tank Clarifying Circular Daf System Dissolved Air Flotation
  • Oil Water Separation Coagulant Tank Clarifying Circular Daf System Dissolved Air Flotation
PrevNext
Oil Water Separation Coagulant Tank Clarifying Circular Daf System Dissolved Air Flotation Oil Water Separation Coagulant Tank Clarifying Circular Daf System Dissolved Air Flotation

Oil Water Separation Coagulant Tank Clarifying Circular Daf System Dissolved Air Flotation

  • Product Item:DAF-030
  • Capacity:2-150m3/hr
  • Material :Carbon steel SUS304,SUS316,FRP
  • Voltage: 380V 3 phase 50Hz or according to your requirements
  • MOQ:1Set, OEM accepted
  • DAF Systems  , Clarifying  , Micro Bubble Generator  , Industrial  , Daf sludge Separator
    Inquiry Send Email PDF

    Description

    Dissolved air flotation Description


    DAF is designed to mainly remove fats, oils and grease (FOG), suspended solids (TSS), parts of biological oxygen demand (BOD) and chemical oxygen dem and (COD) that hard to be dissolved in water and other pollutants from waste water. The process is simple - tiny bubbles attach to solid contaminants causing them to float and then sludge is skimmed off the surface of the water - but designing a DAF system for a real-world application isn't quite as simple.

    DAF Dissolved air flotation price (DAF) is used to treat wastewater that Contain free floating or emulsified oil, dissolved heavy metals, soaps ,surfactants ,and many other waste streams. With the features of lower power consumption, high treat efficiency, simple installation and maintenance , it is one of the most popular Dissolved air flotation clarifier in China.daf for industrial oily water treatment.


    Dissolved Air Flotation Feature


    Flow rate of one set: 1-200 m³/h.
    Recycling flow dissolved air flotation.
    High efficiency pressurization system providing high quantity dissolved-air water to create micro bubbles.
    Custom design on different dissolved air flotation equipment and recycle flow ratio according to the type of wastewater treatment requirement to achieve target removal effect and stability.
    Adjustable PP chain type skimmer to suit the different quantity of sludge.
    Integrated coagulation flocculation tank and cleaning water tank(as optional)is
    available to save the space and cost.
    Automatic and remote controllable.
    Material of construction: carbon steel epoxy painted, carbon steel FRP line, SS304/SS316L.


    Dissolved Air Flotation Available Options


    Access platforms with ladder or stairs
    Automatic sludge pump out packages
    Chemical pretreatment systems
    Concrete tank designs for large in ground installations
    Duplex systems for redundancy
    Effluent monitoring
    Effluent sampling
    Explosion-proof design
    Flash mix/flocculation tanks with mixers
    Full FRP or stainless steel construction
    Influent equalization
    Influent / effluent lift stations
    Instrumentation and controls
    Removable covers with gaskets
    Integral mechanical sludge thickener
    On board reagent storage (day tanks)
    Pilot size units for on-site testing
    Potable water design
    Special coatings
    Sludge handling and dewatering


    Dissolved Air Flotation Applications


    Paper-making waste water treatment for fiber recycling.
    Paint, printing and dyeing waste water treatment for color reduction.
    Chemical waste water treatment.
    Food waste water treatment.
    Oil refinery for separating oil and impurity.
