Description
Efficient High Quality Tubular Micro Porous Aerator
Tubular micro porous aerator is newly used micro porous aeration equipment in industrial wastewater and municipal wastewater biological treatment process; single large amount of ventilation, low bottom resistance, strong enhance ability and high ox-ygen transfer efficiency; there are large number of perforations on the most important parts " diaphragm ", when the air supply hole is open, micro-bubbles form, the hole will close automatically when the wind stops, which avoids sewage and debris to enter the pipe and prevent clogging of the aeration head.
Aeration tube can be connected on one side or in pairs to different rectangular and round tubes (ABS material) with the appropriate adapter. The membranes are manufactured with premium quality EPDM material and are available with fine or coarse-bubble perforation. The support tubes(ABS or PVC material)can be reused when membranes are replaced.
Tubular Micro Porous Aerator Technical Table
| Model | φ63*500 | φ63*750 | φ63*1000 |
| MOC | EPDM/Silicon membrane | EPDM/Silicon membrane | EPDM/Silicon membrane |
| ABS /PP carrier plate | ABS /PP carrier plate | ABS /PP carrier plate | |
| Length | 500mm | 750mm | 1000mm |
| Connector | 3/4 NPT | 3/4 NPT | 3/4 NPT |
| Flow range | 2-14m³/h | 5-20m³/h | 6-28m³/h |
| Bubble Size | 0.8-2mm | 0.8-2mm | 0.8-2mm |
| Service Area | 0.75-2.5m² | 1.0-3.0m² | 1.5-3.5m² |
| Service Life | >8 year | >8 year | >8year |
DAGYEE Diffuser Features
- High shelf and service life
- Very fine bubble aeration
- Efficient oxygen transfer rate
- Non-clogging
- Low maintenance
- Good Mechanical strength
- High temperature resistance
Air Diffuser Application
- Preservation aeration of waste water
- Oxygenation of activation basins
- Oxygenation to stabilize sludge
- Aeration of rivers and lakes
- Aeration of fish ponds
-
CO admission for neutralization
