  • SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP
  • SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP
  • SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP
  • SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP
  • SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP
  • SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP
PrevNext
SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP

SUS304 316 Dissolved Air Flotation Filter Packaging Machine Liquid Separation High Quality WWTP

  • Product Item:DAF-001
  • Capacity:2-150m3/hr
  • Material :Carbon steel SUS304,SUS316,FRP
  • Voltage: 380V 3 phase 50Hz or according to your requirements
  • MOQ:1Set, OEM accepted
  • Plastic Wrappers Dissolved Air Flotation  , Clarifying Dissolved Air Flotation Industrial Daf Systems  , Micro Bubble Generator Dafsludge Separator
    Inquiry Send Email PDF

    Description

    What Is DAF Dissolved air flotation

    DAF Units Dissolved air flotation is one of the most effective methods whose specific gravity is close to 1.0 from water.Dissolved air flotation is liquid-solid or liquid-liquid separation process to remove tiny suspended solids that density close to the water,  oil and grease etc.DAGYEE dissolved air flotation is an innovation combined with traditional dissolved air flotation concept and modern technology.

    Why Choose DAF Dissolved Air Flotation

    • Total suspended solids (TSS) reduced by up to 97.
    • Chemical oxygen demand (COD) removal rate of up to 60-80%.
    • Integrated sludge hopper for easy removal of solid deposits .
    • The DAF area provides a static space for the formation of the float.
    • Heavy-duty, fully protected, counter-current surface separator that removes surface float.


    DAF Dissolved Air Flotation Process



    DAGYEE DAF Dissolved Air Flotation Advantage

    • The most effective white water / recycling design. Large effective settling area.
    • With optional chemical processing stage improved separation efficiency.
    • Compact clarifier and reaction cell design surface loading up to 15m3/m2hr.
    • Rugged design for easy understanding, operation and maintenance.
    • Carbon steel and stainless steel body material design, the lowest cost of ownership.


    DAF
    Model
    Qmax.
    (m3/h)
    PhysicalDimensions(m) Weight
    (Kg)
    Operating
    Weight(kg)
    Power(kw)
    L/L1
    W/W1
    H/H1
    Refluxpump
    Kw
    Air compressor
    kw
    Skimmer
    DAF-002 2 3.4/2.5 2.4/1.16 2.2/1.7 1300 4000 0.75 0.55 0.2
    DAF-003 3 3.7/2.8 2.4/1.16 2.2/1.7 1500 5000 0.75 0.55 0.2
    DAF-005 5 4/3 2.4/1.16 2.2/1.7 1600 7000 1.1 0.55 0.2
    DAF-010 10 4.65/3.8 2.7/1.36 2.4/1.9 2000 12000 1.5 0.55 0.2
    DAF-015 15 5.6/4.5 2.9/1.66 2.5/2 2200 18000 2.2 0.75 0.2
    DAF-020 20 5.9/4.8 3.2/1.96 2.5/2 3000 22000 3 0.75 0.2
    DAF-030 30 6.8/5.5 3.2/2.16 2.7/2.2 3800 32000 3 0.75 0.4
    DAF-040 40 8/6.7 3.6/2.6 2.7/2.2 5000 45000 5.5 0.75 0.4
    DAF-050 50 8.4/7 3.6/2.6 2.7/2.2 5500 55000 7.5 0.75 0.4
    DAF-060 60 9.9/8.4 3.8/2.8 2.9/2.4 6000 66000 7.5 1.5 0.4
    DAF-070 70 10.4/9 3.8/2.8 2.9/2.4 6500 75000 11 1.5 0.4
    DAF-080 80 10.8/9.4 4/3 2.9/2.4 7500 100000 11 1.5 0.4
    DAF-100 100 12.1/10.6 4.2/3.2 2.9/2.4 9000 110000 15 1.5 0.4
    DAF-120 120 12.5/11.4 4.4/3.4 2.9/2.4 10000 130000 15 1.5 0.4


    DAF Dissolved Air Flotation Application


    Slaughterhouses
    Meat processing and pack- ing
    Fish processing Dairies
    Convenience food production
    Margarine production Oil and fat refineries Canneries
    Industrial kitchens and can- teens
    Fast food providers Soap works Cosmetics industry Textile industry Chemical industry
    Petrochemical industry Iron and steel industry Metal processing Galvanizing, electroplating Land remediation
