Description
EDI Reverse Osmosis Ro Water System
Product description
1. Resource: RO water, conductivity <20μ s/cm, better <10μ s/cm
2. PH: 6.5-9.0
3. Water temperature: 5-35℃
4. Hardness(as CaCO3): <0.5ppm
5. Organics: <0.5ppm, TOC recommended to be 0 ppm
6.Oxidizers: <0.05ppm, Cl2: 0.05ppm; O3: 0.02ppm, better both to be 0 ppm
7.Metals: <0.01ppm
8.Silica: <0.5ppm
9.Carbon dioxide: <5ppm
10.Oil: not detectable
Reverse Osmosis Ro System Water Features
- High-precision filter, the pore size is nanometer, the best water quality
-
Automatic switching of manual/electric control system;
-
With self-check function, automatic boiling water system without water point, water full stop, no pressure protection and other safety devices;
- With open RO membrane automatic cleaning and automatic double cleaning of the water tank, it can extend the service life of the RO membrane;
-
With online water quality monitoring (conductivity display), flow and pressure online display functions;
- Equipment integration, simple installation, simple operation, no special responsibilities; Equipment failure has an automatic alarm function;
- High water production, high desalination rate and long service life;
- Core components (pumps, reverse osmosis membranes, electronic control systems, etc.) imported/domestic joint venture brands; The equipment rack is made of stainless steel, the low-pressure pipe is made of UPVC, and the high-pressure pipe is made of SUS304 stainless steel.
Reverse Osmosis Ro System Water Process
1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter.
2.Quartz sand filter-- get rid of turbidity, suspended matter, organic matter, colloid.
3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter.
4. Softener(Optional)--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um.
6. High pressure pump-- Provide the high pressure to RO membrane .
7.RO Reverse Osmosis Unit -- main part of the plant. RO membrane's desalting rate can reach 99%.
8. Storage Tank, Achieve treatment effect.
Reverse Osmosis Ro Systems Case
