  • Dissolved Air Flotation Packaging Electrocoagulation Daf System
  • Dissolved Air Flotation Packaging Electrocoagulation Daf System
  • Dissolved Air Flotation Packaging Electrocoagulation Daf System
  • Dissolved Air Flotation Packaging Electrocoagulation Daf System
  • Dissolved Air Flotation Packaging Electrocoagulation Daf System
  • Dissolved Air Flotation Packaging Electrocoagulation Daf System
PrevNext
Dissolved Air Flotation Packaging Electrocoagulation Daf System Dissolved Air Flotation Packaging Electrocoagulation Daf System Dissolved Air Flotation Packaging Electrocoagulation Daf System Dissolved Air Flotation Packaging Electrocoagulation Daf System

Dissolved Air Flotation Packaging Electrocoagulation Daf System

  • Product Item:DAF-001
  • Capacity:2-150m3/hr
  • Material :Carbon steel SUS304,SUS316,FRP
  • Voltage: 380V 3 phase 50Hz or according to your requirements
  • MOQ:1Set, OEM accepted
  • Caron Steel Dissolved Air Flotation  , Daf Sludge Separator  , Clarifying  , Dissolved Air Flotation  , Industrial  , Daf Systems  , Micro Bubble Generator
    Inquiry Send Email PDF

    Description

    What Is DAF Dissolved air flotation



    WWTP DAF unit Industrial Wastewater,Oil Water Separator Wastewater Plant Treatment DAF Dissolved air flotation is an efficient flotation method for water clarification. The term refers to the method of producing flotation by dissolving air in the water under pressure and then releasing the pressure. When the pressure is released the solution becomes supersaturated with air as millions of small bubbles form. These bubbles attach to any particles in the water causing their density to become less than that of water. The particles then rapidly float to the surface for collection and removal, leaving the clarified water behind.




    As a waste water process, DAGYEE DAF Dissolved air flotation is widely used in sewage treatment and water purification engineering. DAF dissolved air flotation is suitable for :


    • Increase effluent recycling and fresh water reusing in paper and pulp
    • Removal of heavy metal ions
    • Separation of oil refinery effluent
    • Removal of tannery wastewater
    • Removal of chromaticity and impurities in printing and dyeing wastewater
    • Solid-liquid separation of sewage and membrane after all kinds of bio-treatment
    • Sludge concentration (capacity: 20%~ 30%, except the dedicated device which can be designed according to the requirements)




    Why Choose DAF Dissolved Air Flotation

    • Total suspended solids (TSS) reduced by up to 97
    • Chemical oxygen demand (COD) removal rate of up to 60-80%
    • Integrated sludge hopper for easy removal of solid deposits .
    • The DAF area provides a static space for the formation of the float.
    • Heavy-duty, fully protected, counter-current surface separator that removes surface float


    DAF Dissolved Air Flotation Process





    DAGYEE DAF Dissolved Air Flotation Advantage


    • The most effective white water / recycling design. Large effective settling area.
    • With optional chemical processing stage improved separation efficiency.
    • Compact clarifier and reaction cell design surface loading up to 15m3/m2hr.
    • Rugged design for easy understanding, operation and maintenance.
    • Carbon steel and stainless steel body material design, the lowest cost of ownership.


    DAF
    Model
    Qmax.
    (m3/h)
    PhysicalDimensions(m) Weight
    (Kg)
    Operating
    Weight(kg)
    Power(kw)
    L/L1
    W/W1
    H/H1
    Refluxpump
    Kw
    Air compressor
    kw
    Skimmer
    DAF-002 2 3.4/2.5 2.4/1.16 2.2/1.7 1300 4000 0.75 0.55 0.2
    DAF-003 3 3.7/2.8 2.4/1.16 2.2/1.7 1500 5000 0.75 0.55 0.2
    DAF-005 5 4/3 2.4/1.16 2.2/1.7 1600 7000 1.1 0.55 0.2
    DAF-010 10 4.65/3.8 2.7/1.36 2.4/1.9 2000 12000 1.5 0.55 0.2
    DAF-015 15 5.6/4.5 2.9/1.66 2.5/2 2200 18000 2.2 0.75 0.2
    DAF-020 20 5.9/4.8 3.2/1.96 2.5/2 3000 22000 3 0.75 0.2
    DAF-030 30 6.8/5.5 3.2/2.16 2.7/2.2 3800 32000 3 0.75 0.4
    DAF-040 40 8/6.7 3.6/2.6 2.7/2.2 5000 45000 5.5 0.75 0.4
    DAF-050 50 8.4/7 3.6/2.6 2.7/2.2 5500 55000 7.5 0.75 0.4
    DAF-060 60 9.9/8.4 3.8/2.8 2.9/2.4 6000 66000 7.5 1.5 0.4
    DAF-070 70 10.4/9 3.8/2.8 2.9/2.4 6500 75000 11 1.5 0.4
    DAF-080 80 10.8/9.4 4/3 2.9/2.4 7500 100000 11 1.5 0.4
    DAF-100 100 12.1/10.6 4.2/3.2 2.9/2.4 9000 110000 15 1.5 0.4
    DAF-120 120 12.5/11.4 4.4/3.4 2.9/2.4 10000 130000 15 1.5 0.4



    DAF Dissolved Air Flotation Application

    Slaughterhouses
    Meat processing and pack- ing
    Fish processing Dairies
    Convenience food production
    Margarine production Oil and fat refineries Canneries
    Industrial kitchens and can- teens
    Fast food providers Soap works Cosmetics industry Textile industry Chemical industry
    Petrochemical industry Iron and steel industry Metal processing Galvanizing, electroplating Land remediation
